- Water Disinfection
- UV-C LED Reactor
- AℓNUV_Aqua
ULR24A, UV-C LED resin reactor
- Part name ULR24A
- Max water flow(2.0m/s) [L/min] 8.0
-
UV dose(10mJ/cm2)
at. 265nm [L/min] 5.9 -
UV dose (30mJ/cm2)
at. 265nm [L/min] 1.6 -
UV dose (40mJ/cm2)
at. 265nm[L/min] 1.2 - Power consumption [W] 6.8
- Body material Resin
- Fittings [inch] 1/2
- Size(L×W×H) [mm] 186×68×68
Vin=DC24V
※1 UV transmittance 98%, Typical value measured by biodosimeter using Bacteriophage Qβ (Initial Performance)
This ULR24A is Tested and Certified by NSF International against
NSF/ANSI Standard 55 for materials and structural integrity requirements.
※1 UV transmittance 98%, Typical value measured by biodosimeter using Bacteriophage Qβ (Initial Performance)
This ULR24A is Tested and Certified by NSF International against
NSF/ANSI Standard 55 for materials and structural integrity requirements.
Applications
Water purifier, Water dispenser, Medical measurement device, etc.
- High Performance : Equipped with 265nm UV-C LEDs that have high disinfection capability for viruses and bacteria, including chlorine-resistant microorganisms.
- High Efficiency : Achieves high disinfection performance with a water rectificationmechanism and light distribution technology.
- Low Pressure Loss : Lowest pressure loss in the industry.
- Immediacy : Can utilize high disinfection effect immediately upon startup.
- Ecology : Environmentally friendly mercury-free.
Outline dimensions (Unit:mm)
