• Surface & Air Disinfection
  • Compact UV-C LED Module
  • AℓNUV_Pure

Compact UV-C LED module, ULM0008A

Downloading Materials
  • Small Size
  • Water Proof
  • Part name ULM0008A

Applications

  • Tank water disinfection
  • Surface disinfection of filters and drain pans

Compact disinfection module with waterproof structure
  • Equipped with 265nm UV-C LED that is highly effective in disinfecting bacteria, viruses, and chlorine-resistant pathogens.
  • Small size and simple structure.
  • Can be installed in narrow spaces such as inside air conditioners, manufacturing equipment, and industrial equipment.
  • Waterproof and dustproof performance equivalent to IP54.

Specifications
※Ta=25℃、IF=170mA
Front illuminance is measured at a position 20mm from the back of the module.
Part name: ULM0008A Min. value Standard value Max. value Units
Operating temperature -25 --- 60 ℃
Storage temperature -25 --- 70 ℃
Storage humidity --- --- 90 %Rh
Input current 100 --- 270 mA
Forward voltage 5.1 --- 7.6 V
Front illuminance 1.8 --- 4.8 mW/cm²
Wavelength 258 265 270 nm
Wire length 275 mm
IP rating IP54 equivalent -
※The products, specifications, external shapes, etc. listed on this sheet are subject to change without prior notice due to product improvements, etc.

Outline dimensions (Unit:mm)
